eCADSTAR is now offering users an integrated 3D mechanical check. In the library, we simply pair our footprints with models and in our PCB design we can import mechanical data and run collision and clearance checks. We can check from devices to mechanical data and from track elements to mechanical data.
In this video we’re going to take a quick look at the versatility eCADSTAR offers designers with respect to Thermal pad connections. This is a great example. Here we have a net with 4 different pad sizes. The smallest being […]
